16 IP channel max, up to 24MP resolution
Record Rate 320 Mbps (160 Mbps when AI function enabled)
VGA/HDMI up to 3840x2160 output
16-ch synchronous playback
2 SATA interfaces, up to 10 TB for a single HDD, Gigabit LAN
PoE: Max 25.5W for single port, 130W total rated power, 80% control for protection, 16 ports (IEEE802.3af/at), 1-8 PoE Ports support ePoE & EoC
Up to 4 Channel video metadata, Up to 12 Channel perimeter protection, SMD Plus, Up to 4 Channel video stream face recognition, Up to 16 face pictures/sec processing, Up to 20 face databases with 200,000 face images in total
No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB
1U 19” chassis, mouse included
Free IP monitoring software available
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, etc., ONVIF Version 2.4 conformance
