HDCVI is an optimal solution for megapixel high definition application, featuring non-latent long-distance transmission at lower cost over standard RG-75 type cable. It incorporates both cameras and DVRs, and the system is star topology structured. DVR is served as a node to have an over coax P2P (Point-to-Point) transmission to camera. Cable selection is based on transmission distance: cable 75-3 and 75-5 are recommended for transmission within 500 meters, cable 75-5 and above for over 500 meters. Connector or jointing technology could be applied for connecting and the installation is exactly the same as that of conventional analog devices, which posts no special requirements either for indoor or outdoor scenarios with better anti-interference capability offered.
- 1/2.8” Sony Exmor CMOS, 1080P(1920×1080) @25FPS max
- Minimum illumination: Color: 0.05 Lux/F1.6, B/W: 0.005Lux/F1.6
- True Day/Night with ICR Filter, BLC / HLC / DWDR, 3D DNR
- 5.1mm~61.2mm (12x Optical zoom) (51.3° ~ 4.6°)
- Pan: Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°,auto flip 180°
- Preset Speed: Pan: 300° /s; Tilt: 200° /s, Presets: 300
- 1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch)
- 1 Audio channel In, 2/1 Alarm In/Out, RS485
- IP66, IK10, -10°C~+60°C outdoor/indoor use
- Power: AC24V/1.5A(±10%), 10W max
- 24 VAC PSU included
